Specifications
- Voltage – 5 or 10V DC
- Current – 30 mA max
- Output 1 – ±5V or ±10 V full scale, bipolar, jumper selectable
- Output 2 – 4-20mA full scale unipolar
- Input Range – 5 to 50 mV full scale, coarse and fine adjust
- Dynamic Response – DC to 1000Hz
- Zero Offset Range – ± 50% full scale output, Coarse and fine adjust
- Nonlinearity – 0.01% full scale
- Temp. Coefficient – 0.004%/°F max
- Zero Temp. Coefficient – 0.5µV/°F max
- Operating temperature – 32°F to 158°F
- Dimensions – 0.70 in x 3.90 in. x 2.30 in.
- Mounting – 35mm DIN rail
- DC – 10-28 VDC
